RIGOL

Chapter 2 Front Panel Operations

2-100

DG1000Z User’s Guide

System Set

Power On Set

Set the configuration to be used when the instrument is powered on the next time to

“Default” or “Last”. The default setting is “Default”.
 Last: includes all system parameters and states, except channel output state

and clock source.

 Default: denotes the factory defaults except certain parameters (such as

Language).


Press UtilitySystemPower On to select the desired configuration type. This
setting is stored in non-volatile memory and will not be influenced by the Set To

Default operation.

Clock Source

DG1000Z provides an internal 10MHz clock source and accepts external clock source

from the [10MHz In/Out] connector at the rear panel. It can also output clock

source from the [10MHz In/Out] connector for other devices.


Press UtilitySystemClk Src to select “Int” or “Ext”. The default is “Int”. If
“Ext” is selected, the instrument will detect whether a valid external clock signal is

input from the [10MHz Out/In] connector at the rear panel. If no valid clock

source is detected, the prompt message “Not detect a valid external clock!” would be

displayed and the clock source would be switched to “Int”.

You can synchronize two or more instruments by setting the clock source. When two

instruments are synchronized, the “Align Phase” function can not be used. “Align

phase” is only applicable to be used to adjust the phase relation between two output

channels of the same instrument and can not be used to change the phase relation

between the output channels of two instruments. Of course, you can change the

phase relation between two instruments by changing the “Start Phase” of each

channel.

Sync methods for two or more instruments:
 Synchronization between two instruments:

Connect the [10MHz In/Out] connector of Generator A (“Internal” clock) to

the [10MHz In/Out] connector of Generator B (“External” clock) and set the

output frequencies of A and B as a same value to realize synchronization

between two instruments.

 Synchronization among multiple instruments:

Divide the 10MHz clock source of a Generator (“Internal” clock) into multiple

channels, and then connect them to the [10MHz In/Out] connectors of other
