RIGOL Chapter 5 Specifications
5-2 DG1000Z User’s Guide
Signal Characteristics
Square
Rise/Fall Time
Typical (1Vpp)
<10ns
Overshoot
Typical (100KHz, 1Vpp)
≤5%
Duty Cycle
0.01% to 99.99%
(limited by the current frequency setting)
Non-symmetry 1% of period+5ns
Jitter (rms)
Typical (1MHz, 1Vpp, 50Ω)
≤5MHz: 2ppm+200 ps
>5MHz: 200ps
Ramp
Linearity
≤1% of peak output
(typical, 1kHz, 1Vpp, 100% Symmetry)
Symmetry 0% to 100%
Pulse
Pulse Width
16ns to 999.999 982 118ks
(limited by the current frequency setting)
Duty Cycle
0.001% to 99.999%
(limited by the current frequency setting)
Leading/Trailing
Edge Time
≥10ns
(limited by the current frequency and pulse width settings)
Overshoot
Typical (1Vpp)
≤5%
Jitter (rms)
Typical (1Vpp)
≤5MHz: 2ppm+200ps
>5MHz: 200ps
Arb
Waveform Length
8Sa to 8Mpts (16Mpts optional)
Vertical Resolution 14bits
Sample Rate
200MSa/s
Minimum Rise/Fall
Time
Typical (1Vpp)
<5ns
Jitter (rms)
Typical (1Vpp)
≤5MHz: 2ppm+200ps
>5MHz: 200ps
Edit Method Edit Points, Edit Block, Insert Waveform
Harmonic
Harmonic Order
≤8
Harmonic Type Even, Odd, All, User
Harmonic Amplitude can be set for all harmonics
Harmonic Phase can be set for all harmonics
