Eicon Networks 1530 User Manual
Page 55
Security
55
5.
To insert a new filter, click the ‘+’ symbol.
6.
The ‘Edit Filters’ page appear.
7.
Define the settings for the filter using the drop-down menus and click ‘Done’.
The following diagram shows a quick description of what each field means. For more details
on the available options, see
8.
When finished, click the ‘Save’ button.
Note: Two other options, the ‘Select the operation...’ menu and the ‘Do it!’ button, are located at the
bottom of the ‘Edit Filters’ page. These options allow you to delete filters, or copy filters from one profile
or another, and are not used for defining a filter.
‘Plus’
symbol
Action
Direction
Source /Destination
Location
Protocol
Address
