Security
49
Remote Management
By default, the Eicon 1530 allows remote devices to access its configuration interfaces via the
external network. This feature can be disabled; however, this does not affect traffic on the local
LAN created by the Eicon 1530. If the local LAN is connected to other networks, these
computers will continue to have access to the Eicon 1530, even if remote management is
disabled. Consider the following topology:
In the above example, all computers on the two LANs have access to the Eicon 1530
configuration interfaces. However, remote computer A is blocked as it must go through the
external network to access the Eicon 1530.
Disabling Remote Management
To disable remote management:
Note: Remote security is implemented using IP filtering. In the web interface, expand the ‘IP’ section
and click ‘Filters’.
