Selecting an Interface Cable 100
Interface Cables available from Eicon Networks
The Eicon 1530 can connect to Customer Service Units (CSUs) or Data Service Units (DSUs)
which support one of the V.24 or V.35 interfaces, including compatible Eicon Networks
Eiconcards (such as the C series) using a V.24 cable.
Note: Two Eicon 1530 devices cannot be connected back-to-back.
The following table lists the most common connections supported by the VHSI port, and
specifies the part number of the required Eicon Networks cable. For information on making
your own cables, see “Interface Cable Specifications” on page 101.
To use an interface, simply connect the appropriate cable. The Eicon 1530 recognizes the cable
and automatically configures the port for that interface. Consult the documentation which came
with your networking software for more information about port configuration.
Interface Connection Part #
V.24 to V.24 DCE 300-077
to V.24 DTE 300-078
V.35 to V.35 DCE 300-076
to V.35 DCE (France) 300-083
