Graphics
15.1
15
TNC 320 | User's Manual
HEIDENHAIN Conversational Programming | 3/2014
477
Repeating graphic simulation
A part program can be graphically simulated as often as desired. To
do so you can reset the graphic to the workpiece blank.
Function
Soft key
Show the unmachined workpiece blank
Tool display
Regardless of the operating mode, you can also show the tool
during the simulation.
Function
Soft key
Program Run, Full Sequence / Program Run, Single
Block
Test Run
