HEIDENHAIN TNC 320 (77185x-01) - Manual (Page 258)

Programming: Subprograms and program section repeats
8.4 Any desired program as subprogram
8
258
TNC 320 | User's Manual
HEIDENHAIN Conversational Programming | 3/2014
Calling any program as a subprogram
To select the functions for program call, press the
PGM CALL key
Press the
PROGRAM soft key: The TNC starts
the dialog for defining the program to be called.
Use the screen keyboard to enter the path name
(
GOTO key), or
press the SELECT PROGRAM soft key for the TNC
to display a selection window in which you can
select the program to be called. Confirm with the
END key
If the program you want to call is located in the same
directory as the program you are calling it from, then
you only need to enter the program name.
If the called program is not located in the same
directory as the program you are calling it from,
you must enter the complete path, e.g.
TNC:
\ZW35\SCHRUPP\PGM1.H
If you want to call a DIN/ISO program, enter the file
type .I after the program name.
You can also call a program with Cycle
12 PGM CALL.
As a rule, Q parameters are effective globally with
a
PGM CALL. So please note that changes to Q
parameters in the called program can also influence
the calling program.
Danger of collision!
Coordinate transformations that you define in
the called program remain in effect for the calling
program too, unless you reset them.
