22
4. Specifications
The MSE 1000 is an advanced system for performing production integrated
measurements at high levels of precision and accuracy. The modules described in these
instructions are designed for indoor use only. The MSE 1000 components shall only be
installed as described in these instructions. Mounting, installation and maintenance are to
be performed by qualified personnel only.
MSE 1332
747509-01 MSE 1401
747507-01 MSE 1401
747507-02 MSE 1501
747508-01
Power consumption 3.2 W
1)
6.1 W
2)
3.7 W
2)
Data transfer Standard Ethernet, IEEE 802.3
Addressing Fixed IP address or DHCP
Operating temperature 0 °C ... 45 °C
Storage temperature -20 °C ... 70 °C
Relative humidity † 80 %
Altitude † 2000 m
Degree of protection IP 65 IP 40 IP 65
Overvoltage category II, intended to be supplied from the building wiring
Pollution degree 2
Mass 420 g 420 g 440 g 460 g
Input pressure max. 700 kPa
1)
Power requirement of the module. Connected sensors must be considered additionally.
2) Power requirement of the module including active inputs and outputs supplied internally.
Refer to “Relay outputs”and “Switching inputs” on page 204 for further information.
Notice
Refer to the MSE 1000 Product Information (ID 736907-xx) for power
consumption calculation examples.
