Grass Valley UniConfi NVISION Series v.2.1 User Manual

Uniconfi g, User’s guide

background image

UniConfi g

NVISION Series Router Confi guration Utility v12.0.0

User’s Guide

UG0022-05

25 Nov 2014

Table of contents

Document Outline

Preface
- Chapter Structure
- The PDF Document
- Terms, Conventions and Abbreviations
Introduction
- Product Overview
- Supported Routers
Configuration Basics
- Before Starting a Configuration
- Launching UniConfig
  - How to Launch UniConfig
  - How to Connect to a Router Control Card
- Viewing Configurations
  - How to View Current Configuration Settings
- Writing Changes to the Control Card
  - How to Write Changes
- Applying Configurations to Another Control Card
  - How to Apply a Configuration to Another Control Card
- USB-to-Serial Adapters
- Network Basics
Installation
- Preparing for Installation
- Installing UniConfig
  - How to Install UniConfig
Communication
- Communicating with a Router
- Serial and Ethernet Settings
- Communications Options
  - Retaining Serial Port Settings
  - Advanced Ethernet Communication Settings
- Disabling an Ethernet Port
  - How to Disable Communication with a Control Card
- Reading and Writing Control Card Configurations
  - Reading a Control Card’s Configuration
  - Writing a Control Card’s Configuration
Partitions and Signal Types
- About Partitions
- Configuration Window
- Partition Types
- Setting Up Partitions
  - Standalone v. Expanded Routers
  - Updating Partitions
- Mono v. Stereo Audio
- Defining a ‘Monitor’ Level
- Defining an ‘Output Follow’ Level
  - Creating an Output Follow Level
Switch Point Settings
- Background
  - Redundant v. Dual Video Reference
- The Switch Point Setup Window
- About Video Signal Fields and Frames
- Setting Switching Parameters
Machine Control
- Background Information
- The Port Configuration Window
  - Machine Control Port Commands
- Setting Up Machine Control Ports
  - How to Configure Machine Control Ports
Connections Window
- Introduction
  - Writing Connections Reports
- The Connections Window
- Setting Connection Window Options
- Viewing Diagnostic Crosspoint Data
  - How to View Crosspoints
- Performing Takes
- Special Takes
EC9535
- Setting Up EC9535 Communication
  - Connections
  - EC9535 and Router Baud Rates
- Setting Up EC9535 Partitions
  - How to Set Up Partitions for an EC9535
- Setting Up EC9535 Switch Points
  - How to Make Switch Point Settings for the EC9535
NV8500 Monitors
- Monitor Overview
- UniConfig Settings
  - Mapping to the Monitor Level
- Using the Monitor Level
Locks
- How to Remove Locks
Salvos
- Introduction
- Creating a Salvo
  - How to Create a Salvo
- Building a Salvo
- Salvo Management
Firmware
- Viewing Control Card Firmware
  - How to View the Software List Using the ‘Basic’ Setting
  - How to View the Software List Using the ‘Expanded’ Setting
- Uploading a Firmware File
  - How to Upload New Firmware
- Using Flash Configuration Files
System Status
- Viewing System Status
  - How to View System Status
- Performing System Tasks
Logs
- Using the Logs Window
  - Logging Modes
  - Operations
Technical Details
- Router Expansion
- Connectors
- Mono and Stereo Configuration Methods
  - Method 1
  - Method 2
Glossary
Index
