15. DSP Implementation Guide
Plug-in Processing in the v.5 Mixer
There are two levels of DSP available in 2d Expanded interfaces:
• The basic 2d plug-in set, which is only accessible via the channelstrip inserts
• The +DSP plug-in set, which is available via the inserts or graphs
You can see a comparison of the two DSP packages in the DSP Package Comparison appendix.
Inserts
Click anywhere on an empty insert slot, and you'll see the insert menu:
Figure 15.1: Insert Menu
Here you can select available plug-ins from the categories in the Plug-in menu, or select a Send bus. On
+DSP boxes you can also select Macros and Graphs, which we'll cover in the
Graphs section. Once you have
selected a plug-in, it will be listed in the assigned insert slot:
Figure 15.2: Inserted Plug-in
Clicking on the name of the plug-in will open its UI, and clicking on the disclosure triangles to the right of
the name will open the insert menu.
Plug-in UI's
To open the UI for a plug-in, click on it in the Mixer insert (or double click the plug-in if it is in a graph).
Figure 15.3: M/S Plug-in UI
