Page 63: 8241 - rear panel

Mono Input Channel 8241
7-9
Revision R2005-2
R-Type
:15
0RQR#,QSXW#&KDQQHO#;574#0#UHDU#SDQHO
MICROPHONE INPUT
SEND is permanently live and can be
used as an additional output.
RETURN is activated by the INS
(insert) switch on the module front
panel.
DIRECT OUTPUT
Inputs and Outputs are electronically bal-
anced and connected via 3-pin XLRs and
follow the wiring convention:
PIN 1 = Screen
PIN 2 = In-phase signal (hot)
PIN 3 = Out-of-phase signal (cold)
The 0.25” TRS jack connectors use the
wiring convention:
TIP = In-phase signal (hot)
RING = Out-of-phase signal (cold)
SLEEVE = Screen
IMPORTANT NOTE: Pin 1 on XLR con-
nectors and the ‘sleeve’ connections
on the jack sockets are connected to
the FRAME. This is to ensure that the
console can comply with the Electric
Compatibility (EMC) directive.
