Page 27: Connecting the console frames, 617 &rqqhfwlqj#wkh#frqvroh#iudphv
3-13
Revision R2005-2
R-Type
617
&RQQHFWLQJ#WKH#FRQVROH#IUDPHV
61714
)UDPH#WR#IUDPH#EXV#FDEOH
When linking frames, plug the frame to frame bus cable as shown in the diagram
below.
A. Important information regarding EMC
61715
(DUWK/#39/#*1'#DQG#)UDPH#&RQQHFWLRQV
Figure 3-20 shows the rear panel of the power supply units in a single PSU system.
A 0V stud is provided on the back of the PSU for grounding external equipment.
In addition to the terminal on the back of the PSUs, there is an
0v connection on the
rear of each console frame. This connection is included for connecting external
equipment.
FIG 3-21. Audio Bus connections.
FIG 3-22. 8400 PSU system.
