56
6 O
PERATIONAL FAILURES
6.1 S
TATUS MESSAGES
ALS
306
309
GB
5140 Rewinder control Rewinder control
During problem-free operation,
the rewind unit dancer arm only
moves a minimal distance
around the "control position".
This is the position the dancer
arm takes up after initialisation
of the machine.
– Any force applied that moves the
dancer arm from its control position.
Example: The feed motor is blocked;
the backing paper is not conveyed
quickly enough; as a result the
dancer arm is pulled upwards.
Example: The backing paper is torn;
the dancer arm springs downwards.
£ Press the key.
– This reinitialises the dancer arm
control; the dancer arm moves back
into the control position.
5143 Rewinder Stop – This message appears when the
dancer arm was held against its
upper stop for more than two
seconds.
Effect:
Power to the rewinder motor is
switched off, so that the rewinder can
be turned easily by hand.
This effect is helpful when
installing a new label roll,
because the rewinder can be
turned easily.
£ Press the key to confirm the
error message.
5145 Rewinder full This error can only occur if the
end of a new label roll was glued
on to backing paper that had
already been wound onto the
rewinder.
– The maximum permitted diameter
(205 mm) for the rewinder roll has
been reached.
£ Remove the rewound backing paper
£ Press the key to confirm the
error message.
Status Status text Cause Action to take
[59] List of error messages
