2.4.1
Overview of functions
[22] Functions menu – part 1 (grey shading = function is described in the following).
LABEL SETUP
MACHINE SETUP
INTERFACE PARA
SIGNAL INTERFACE
APPLICATOR PARA
9)
Load prod.profil
Store prod.prof.
> EASYPLUGINTERPR Interface mode
Operation enable
Gap detect mode
Del. prod.profil
Interface
> PLC INTERFACE
Applicator type
Dispense speed
Dispense counter
Spooler mode
End dispense mod
Apply mode
Slew speed
Factory settings
Dispenser ID no.
Disp. end delay
Start mode
Label pitch
Parameter to CF
Spooler size
End pulse width
Start error stop
Lab. stop offset
Auto Sensor Adj.
Offline mode
Start delay
Start offset
Sensor Adjust
Interface delay
> APPLICATOR INT.
Blow on time
7)
Product length
Speed Adaption
Applicator type
Dwell time
6)
Multi label mode
Encoder Type
3)
> COM1 PORT
Apply mode
Restart delay
Label 2 offset
1)
Encoder Resol.
3)
Baud rate
Dwell time
6)
Position timeout
8)
Label 3 offset
1)
Encoder Diameter
3)
No. of data bits
Blow on time
7)
Apply comp. time
Miss. label tol.
Tandem Operation
Parity
Restart delay
Stop count. mode
Tandem Synch.
4)
Stop bits
Position timeout
8)
Label stop quan.
2)
Tandem Distance
4)
Data synch.
Apply comp. time
Light sens. type
Frame error
Labelsen. InType
> ACTIVE INPUTS
Startsen. In.Typ
> NETWORK PARAM.
Start signal
Start disp. mode
IP Addressassign
Inhibit signal
Start error stop
IP address
OD sensor signal
Turn-on mode
Net mask
Language
Gateway address
Access authoriz.
Port address
Material end err
Ethernet speed
Materialend warn
MAC Address
1) Only appears if LABEL SETUP > Multi label mode =
„2 labels/start“ oder „3 labels/start“.
2) Only appears if LABEL SETUP > Stop count. mode = Enabled
3) Only appears if MACHINE SETUP > Speed Adaption = On
4) Only appears if MACHINE SETUP > Tandem Operation =
Enabled
5) Only appears if MACHINE SETUP > OD Sensor mode = „Error“
or „Warning“
6) Only appears if Applicator type = PEP, PEP Blow on, Reverse
PEP or BTS
7) Does not appear if applicator type = PEP
8) Does not appear if applicator type = ASA
9) Only appears with AI board installed
OD Sensor mode
SNMP Agent
OD Sens. polarity
5)
FTP server
WEB server
WEB display refr
Time client
DHCP host name
