PERATION

4.3 U

SING

PRODUCT

PROFILES

ALS

306
309

4.3.1

What are product profiles?

Product profiles are memory locations that can store all
the settings for the machine controls. For recurring
production jobs, they allow you to quickly set the
machine to the respective product.

– Number of memory locations: 16
– The memory locations are numbered. In addition,

you can also enter a text identifier for each memory
location (with a maximum of 9 alphanumeric
characters).

4.3.2

Loading a product profile

CAUTION!

Incorrect settings may lead to production
problems and damage both the unit and the
equipment.

Only staff who are qualified and specially
trained should set up product databases.

Call the

LABEL SETUP > Load prod. profil

function.

– The following message appears when no memory

location is occupied:

– Only occupied memory locations are displayed.
– When memory locations are occupied, the memory

location that was loaded last is displayed first:

Above example: The profile with the ‘xxxxxx’ text
identifier has been stored at the first memory
location.

Press the

or the

button until the profile you

require appears.

Press the

button to load the profile.

– The unit restarts afterwards.
– Display after the restart:

(in dispensing mode, ‘ONLINE’ is replaced by the
current profile name).

4.3.3

Storing a product profile

Selecting the memory location

Call the

MACHINE SETUP > Store prod.prof.

function.

– Display shown when all memory locations are

unoccupied:

– When memory locations are already occupied, the

memory location that was last active is displayed:

– A ‘*’ occurring after the memory location number

indicates that the memory location is already
occupied (here by the ‘customer_xyz’ profile).

Press the

or the

button until you retrieve the

memory location you require (1–16).

Press the

button to activate the memory

location.

– The profile name flashes, and you can now replace

the name using any text you choose.

Entering profile names

Accepting the profile name ‘Product 1’ without
changing it:

Press the

button twice.

– The profile is saved.
– Display:

Changing a profile name:

Press the

button.

– Display:

– The underscore marks the active position.

Press the

or the

button to scroll through the

available characters until the character you require
appears.

Press the

button to accept the character.

– The underscore jumps to the next character.

Enter the next character in the same way.

When you have entered the last character, press the

button.

Load prod. profil
No setup avail.

Load prod. profil
Prof 1 xxxxxx

Prof 1 xxxxxx
Label

Store prod.prof.
Prof 1 Product 1

Store prod.prof.
Prof 5*customer_xyz

Store prod.prof.
Storing…

Store prod.prof.
Prof x _

4.3

USING PRODUCT PROFILES
