2.4 F
UNCTION
DESCRIPTIONS
ALS
306
309
GB
[23] Functions menu – part 2.
SERVICE/DIAGNOS. SERVICE DATA
(continued)
Sensor Test
> MODULE FW VERS
. > DISPLAY DATA
Compactflashtest
System version
Display version
Test functions
System revision
Display serial #
Diagnosis to CF
System date
Remote disp. vers.
2)
Bootloader
Remote disp. #
2)
uMon
Applicator int.
1)
> CF CARD SLOT
Card in slot
> OPERATION DATA
Serv. operations
> MEMORY DATA
Tot. mat. length
Ram memory size
Dispensing cycl.
Flash mem size
Operation time
Default values
> POWERSUPPLYDATA
Type
Version
Serial number
PS temperature
Standby+On time
On time
> CPU BOARD DATA
CPU identifier
PCB Revision
FPGA version
MAC Address
1) Only when applicator
interface is installed.
2) Only if a remote display is
connected.
Serial number
Production date
PCB part number
Board part numb.
