Chapter 4

MVME4100ET Single Board Computer Installation and Use (6806800K76F)

69

Functional Description

4.1

Overview

The MVME4100ET VMEbus board is based on the MPC8548E System on Chip (SoC) processors.
The MVME4100ET provides front panel access to one serial port with a mini DB-9 connector
and two 10/100/1000 Ethernet ports with two RJ-45 connectors. The front panel includes a fail
indicator LED, user-defined indicator LED, and a reset/abort switch.

The MVME721ET transition module provides rear panel access to four serial ports with one
RJ-45 connector per port and two 10/100/1000 Ethernet ports with two RJ-45 connectors. The
transition module also provides two planar connectors for one PIM with front I/O.

The block diagram for the MVME4100ET Single Board Computer is shown in

Figure 4-1

and the

block diagram for the MVME721ET transition module is shown in

Figure 5-2

.
