Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 65
3.3.3.7 MVME721ET PMC I/O Module (PIM) Connectors (J10, J14)
PMC Host I/O connector J10 routes only power and ground from VME P2. There are no Host I/O
signals on this connector. The MVME4100ET routes PMC I/O from J14 of PMC Slot 1 to VME P2
rows A and C. The MVME721ET routes these signals (pin-for-pin) from VME P2 to PMC I/O
Module connector J14. See
Table 3-15 for the pin assignments.
23 SP3RTS PMC1_IO46 VD24 PMC1_IO45 E2-3-
24 GND PMC1_IO48 VD25 PMC1_IO47 E2-3+
25 SP4RX PMC1_IO50 VD26 PMC1_IO49 GND
26 GND PMC1_IO52 VD27 PMC1_IO51 E2-2-
27 SP4TX PMC1_IO54 VD28 PMC1_IO53 E2-2+
28 GND PMC1_IO56 VD29 PMC1_IO55 GND
29 SP4CTS PMC1_IO58 VD30 PMC1_IO57 E2-1-
30 GND PMC1_IO60 VD31 PMC1_IO59 E2-1+
31 SP4RTS PMC1_IO62 GND PMC1_IO61 GND
32 GND PMC1_IO64 +5V PMC1_IO63 +5V
Table 3-14 VME P2 Connector Pinouts (continued)
Pin P2-Z P2-A P2-B P2-C P2-D
Table 3-15 MVME721 Host I/O Connector (J10) Pin Assignments
Pin Signal Signal Pin
1 No Connect No Connect 2
3 No Connect No Connect 4
5 +5V No Connect 6
7 No Connect No Connect 8
9 No Connect +3.3V 10
11 No Connect No Connect 12
13 GND No Connect 14
15 No Connect No Connect 16
17 No Connect GND 18
