Hardware Preparation and Installation
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 36
If you are installing the optional MVME721ET transition module, refer to Transition Module on
page 36 for configuration switch settings.
2.5 Installing Accessories
This section describes the procedures for installing the MVME721ET transition module, PMCs,
and the XMCspan on the base board.
2.5.1 Transition Module
The MVME721ET does not support hot swap. You should remove power to the rear slot or
system before installing the module. Before installing the MVME721ET transition module, you
may need to manually configure the switch and install a PMC I/O Module (PIM). Refer to
Chapter 5, Transition Module , for switch settings and PIM installation.
2. The VME SCON SEL switch is OFF to select non-SCON mode. The switch is ON to select always SCON mode. This
switch is only effective when the VME SCON MAN switch is ON.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits or
shorten their life.
Before touching the board or electronic components, make sure that you are working in an
ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel and/or PCB.
Deformation of the front panel can cause an electrical short or other board malfunction.
Board Malfunction
Switches marked as “reserved” might carry production-related functions and can cause the
board to malfunction if their setting is changed.
Do not change settings of switches marked as “reserved”. The setting of switches which are
not marked as “reserved” has to be checked and changed before board installation.
