MOTLoad Firmware
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 106
6.7.2 Image Flags
The image flags of the header define various bit options that control how the image will be
executed.
 COPY_TO_RAM
If set, this flag indicates that the image is to be copied to RAM at the address specified in
the header before control is passed. If not set, the image will be executed in flash. In both
instances, control will be passed at the image offset specified in the header from the base
of the image.
 IMAGE_MCG
If set, this flag defines the image as being an Alternate MOTLoad, as opposed to USER,
image. This bit should not be set by developers of alternate boot images.
 IMAGE_POST
If set, this flag defines the image as being a power-on self-test image. This bit flag is used
to indicate that the image is a diagnostic and should be run prior to running either USER or
MCG boot images. POST images are expected, but not required, to return to the boot
block code upon completion.
 DONT_AUTO_RUN
If set, this flag indicates that the image is not to be selected for automatic execution. A
user, through the interactive command facility, may specify the image to be executed.
Table 6-2 MOTLoad Image Flags
Name Value Interpretation
COPY_TO_RAM 0x00000001 Copy image to RAM at ImageRamAddress before execution
IMAGE_MCG 0x00000002 Alternate MOTLoad image
IMAGE_POST 0x00000004 POST image
DONT_AUTO_RUN 0x00000008 Image not to be executed
MOTLoad currently uses an Image Flag value of 0x3, which identifies itself as an alternate
MOTLoad image that executes from RAM. MOTLoad currently does not support execution
from flash.
