Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 64
3.3.3.6 VMEbus P2 Connector
The VME P2 connector is a 160-pin DIN. Row B of the P2 connector provides power to the
MVME4100ET and to the upper eight VMEbus address lines and additional 16 VMEbus data
lines. The Z, A, C, and D pin assignments for the P2 connector are the same for both the
MVME4100ET and MVME721ET, and are as follows:
Table 3-14 VME P2 Connector Pinouts
Pin P2-Z P2-A P2-B P2-C P2-D
1 SP1RX PMC1_IO2 +5V PMC1_IO1 E1-1+
2 GND PMC1_IO4 GND PMC1_IO3 E1-1-
3 SPITX PMC1_IO6 VRETRY_L PMC1_IO5 GND
4 GND PMC1_IO8 VA24 PMC1_IO7 E1-2+
5 SP1CTS PMC1_IO10 VA25 PMC1_IO9 E1-2-
6 GND PMC1_IO12 VA26 PMC1_IO11 GND
7 SP1RTS PMC1_IO14 VA27 PMC1_IO13 E1-3+
8 GND PMC1_IO16 VA28 PMC1_IO15 E1-3-
9 SP2RX PMC1_IO18 VA29 PMC1_IO17 GND
10 GND PMC1_IO20 VA30 PMC1_IO19 E1-4+
11 SP2TX PMC1_IO22 VA31 PMC1_IO21 E1-4-
12 GND PMC1_IO24 GND PMC1_IO23 GND
13 SP2CTS PMC1_IO26 +5V PMC1_IO25 I2C_SDA
14 GND PMC1_IO28 VD16 PMC1_IO27 I2C_SCL
15 SP2RTS PMC1_IO30 VD17 PMC1_IO29 E1_LINK
16 GND PMC1_IO32 VD18 PMC1_IO31 E1_ACT
17 SP3RX PMC1_IO34 VD19 PMC1_IO33 E2_LINK
18 GND PMC1_IO36 VD20 PMC1_IO35 E2_ACT
19 SP3TX PMC1_IO38 VD21 PMC1_IO37 GND
20 GND PMC1_IO40 VD22 PMC1_IO39 E2-4-
21 SP3CTS PMC1_IO42 VD23 PMC1_IO41 E2-4+
22 GND PMC1_IO44 GND PMC1_IO43 GND
