Controls, LEDs, and Connectors

MVME4100ET Single Board Computer Installation and Use (6806800K76F)

54

63

GND

REQ64#

64

Table 3-6 PMC Slot 1 Connector (J12) Pin Assignments

Pin

Signal

Signal

Pin

1

+12V

TRST#

2

3

TMS

TDO

4

5

TDI

GND

6

7

GND

Not Used

8

9

Not Used

Not Used

10

11

Pull-up to +3.3V

+3.3V

12

13

RST#

Pull-down

14

15

+3.3V

Pull-down

16

17

Not Used

GND

18

19

AD30

AD29

20

21

GND

AD26

22

23

AD24

+3.3V

24

25

IDSEL1

AD23

26

27

+3.3V

AD20

28

29

AD18

GND

30

31

AD16

C/BE2#

32

33

GND

IDSEL1B

34

35

TRDY#

+3.3V

36

37

GND

STOP#

38

39

PERR#

GND

40

41

+3.3V

SERR#

42

43

C/BE1#

GND

44

45

AD14

AD13

46

Table 3-5 PMC Slot 1 Connector (J11) Pin Assignments (continued)

Pin

Signal

Signal

Pin
