Chapter 2
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 25
Hardware Preparation and Installation
2.1 Overview
This chapter provides startup and safety instructions related to this product, and hardware
preparation instruction that includes default switch settings. System considerations and
installation instructions for the base board, PMC, and transition module are also described in
this chapter.
A fully implemented MVME4100ET consists of the following along with the base board:
 Two single-wide or one double-wide PCI Mezzanine Card (PMC) slot for added versatility.
 One transition module for support of the mapped I/O from the MVME4100ET base board
to the P2 connector.
 Up to two optional XMCspan cards.
The following table lists the tasks that you need to do before you can use this board. Read this
entire chapter, including all Cautions and Warnings, before you begin.
Table 2-1 Startup Overview
Task Page
Unpack the hardware. Unpacking and Inspecting the Board on page 26
Configure the hardware by setting jumpers
on the board and RTM. Configuring the Board on page 31 and SEEPROM Address
Switch, S1 on page 82
Install the MVME721ET transition module in
the chassis. Transition Module on page 36
Install PMC module (if required). Installing Accessories on page 36
Install XMCspan module (if required). XMCspan Installation and Use manual (6806800H03)
Install the MVME4100ET in the chassis. Installing and Removing the Board on page 40
Attach cabling and apply power. Completing the Installation on page 41
Install PIM on transition module (if
required). PMC Input/Output Module on page 85
Ensure that the firmware initializes the
MVME4100ET Chapter 6, MOTLoad Firmware
Initialize the board Chapter 6, MOTLoad Firmware
Examine and/or change environmental
parameters. MVME4100ET Single Board Computer Programmer’s
Reference
