3.3.3.2 Ethernet Connectors (J4A/J4B)
There are four 10/100/1000 Mb/s full duplex Ethernet interfaces using the MPC8548E Triple
Speed Ethernet Controllers (TSECs). Two Gigabit Ethernet interfaces are routed to the two
front-panel RJ-45 connectors with integrated LEDs for speed and activity indication. The other
Gigabit Ethernet interfaces are routed to P2 for rear I/O. These connectors use standard pin
assignments and are as follows:
3.3.3.3 PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
There are seven 64-pin SMT connectors on the MVME4100ET to provide 32/64-bit PCI
interfaces and P2 I/O for one optional add-on PMC.
PMC slot connector J14 contains the signals that go to VME P2 I/O rows A, C, D, and Z. The pin
assignments for these connectors are as follows:
Table 3-4 Ethernet Connectors (J4A/J4B) Pin Assignments
Pin # 10/100/1000 Mb/s
1 _DA+
2 _DA-
3 _DB+
4 _DC+
5 _DC-
6 _DB-
7 _DD+
8 _DD-
Table 3-5 PMC Slot 1 Connector (J11) Pin Assignments
Pin Signal Signal Pin
1 TCK -12V 2
3 GND INTA# 4
5 INTB# INTC# 6
7 PMCPRSNT1# +5V 8
