Controls, LEDs, and Connectors

MVME4100ET Single Board Computer Installation and Use (6806800K76F)

50

3.3.3.1

XMC Expansion Connector (J6)

One 76-pin Mictor connector with a center row of ground pins is used to provide XMC
expansion capability. The pin assignments for this connector are as follows:

Table 3-3 XMC Expansion Connector (J6) Pin Assignments

Pin

Signal

Signal

Pin

1

GND

GND

GND

2

3

TX0_P

RX0_P

4

5

TX0_N

RX0_N

6

7

GND

GND

8

9

TX1_P

RX1_P

10

11

TX1_N

RX1_N

12

13

GND

GND

14

15

TX2_P

RX2_P

16

17

TX2_N

RX2_N

18

19

GND

GND

20

21

TX3_P

RX3_P

22

23

TX3_N

RX3_N

24

25

GND

GND

26

27

REFCLK_P

No Connect

28

29

REFCLK_N

No Connect

30

31

GND

GND

32

33

No Connect

No Connect

34

35

No Connect

PCIE_END_N

36

37

INT_N

RESET_N

38
