Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 48
3.3.1 Reset/Abort Switch
The MVME4100ET has a single push button switch to provide both the abort and reset
functions. When the switch is depressed for less than 3 seconds, an abort interrupt is
generated to the MPC8548E PIC. If the switch is held for more than 3 seconds, a board hard
reset is generated. If the MVME4100ET is the VMEbus system controller, a VME SYSRESET is
generated.
3.3.2 LEDs
The table below describes the LEDs on the front panel of the MVME4100ET. Refer to Figure 3-2
on page 47 for LED locations.
Table 3-1 Front Panel LEDs
Label Function Color Description
BFL Board Fail Red This indicator is illuminated during a hard
reset and remains illuminated until
software turns it off. The LED is
controlled by bit 14 (BDFAIL) of the
VSTAT register in the Tsi148.
USR1 User Defined Red/Yellow This indicator is illuminated by S/W
assertion of its corresponding register
bits in the Status Indicator Register. See
the Programmer's Guide for further
details.
GNET1 SPEED TSEC1 Link / Speed Off
Yellow
Green No link
10/100 BASE-T operation
1000 BASE-T operation
GNET1 ACT TSEC1Activity Off
Blinking Green No activity
Activity proportional to bandwidth
utilization
GNET2 SPEED TSEC2 Link / Speed Off
Yellow
Green No link
10/100 BASE-T operation
1000 BASE-T operation
