Hardware Preparation and Installation
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 40
2.5.3 XMCspan
The XMCspan is a carrier module that provides PCI Express expansion capability to the
MVME4100ET. Refer to the XMCspan Installation and Use manual for details about the XMCspan
and the installation procedure.
2.6 Installing and Removing the Board
This section describes a recommended procedure for installing a board module in a chassis.
The MVME4100ET does not support hot swap. You should remove power to the slot or system
before installing the module. Before installing the MVME4100ET, ensure that the serial ports
and switches are properly configured.
Installation and Removal Procedure
Before you install the module, read all cautions, warnings, and instructions described in this
section.
To install the MVME4100ET into your computer chassis, perform the following steps:
1. Attach an ESD strap to your wrist.
2. Attach the other end of the ESD strap to an electrical ground.
The ESD strap must be secured to your wrist and to ground throughout the
procedure.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits or
shorten their life.
Before touching the board or electronic components, make sure that you are working in an
ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel and/or PCB.
Deformation of the front panel can cause an electrical short or other board malfunction.
