Introduction
MVME4100ET Single Board Computer Installation and Use (6806800K76F)
18
Flash
128 MB soldered NOR flash with two alternate 1 MB boot sectors
selectable via hardware switch
H/W switch or S/W bit write protection for entire logical bank
4 GB NAND flash
NVRAM
One 512 KB MRAM extended temperature range
PCI_E
8X Port to XMC Expansion
I/O
One front panel mini DB-9 connector for front I/O: one serial channel
Two front panel RJ-45 connectors with integrated LEDs for front I/O:
two 10/100/1000 Ethernet channels
PMC site 1 front I/O and rear P2 I/O
PMC site 2 front I/O
Ethernet
Four 10/100/1000 MPC8548E Ethernet channels: two front panel
Ethernet connectors and two channels for rear P2 I/O
Serial Interface
One 16550-compatible, 9.6 to 115.2 Kbaud, MPC8548E,
asynchronous serial channel: one channel for front panel I/O
One quad UART (QUART) controller to provide four 16550-
compatible, 9.6 to 115.2 Kbaud, asynchronous serial channels: four
channels for rear P2 I/O
Timers
Four 32-bit MPC8548E timers
Four 32-bit timers in a PLD
Watchdog Timer
One watchdog timer in a PLD
VME Interface
VME64 (ANSI/VITA 1-1994) compliant (3 row backplane 96-pin VME
connector)
VME64 Extensions (ANSI/VITA 1.1-1997) compliant (5 row
backplane 160-pin VME connector)
2eSST (ANSI/VITA 1.5-2003) compliant
ANSI/VITA 1.7-2003 compliant (Increased Current Level for 96 pin &
160 pin DIN/IEC Connector Standard)
VITA 41.0, version 0.9 compliant
Two five-row P1 and P2 backplane connectors
One Tsi148 VMEbus controller
Form Factor
Standard 6U VME, one slot
Table 1-1 Features List (continued)
Function
Features
