Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 49
3.3.3 Connectors
This section describes the pin assignments and signals for the connectors on the
MVME4100ET. The table below lists the standard connectors on the MVME4100ET base board.
Refer to
Figure 3-1 on page 46 for connector locations. Pin assignments for the connectors are
in the following sections. Some connectors use standard pin assignments in compliance with
the VMEbus, IEEE, PCI, and ANSI/VITA specifications. Links to these specifications are located at
Appendix B, Related Documentation, on page 115 .
GNET2 ACT TSEC2 Activity Off
Blinking Green No activity
Activity proportional to bandwidth
utilization
Table 3-1 Front Panel LEDs (continued)
Label Function Color Description
Table 3-2 Base Board Connectors
Reference Designator Function Notes
J6 XMC Expansion 8X PCI-E to XMCSpan
J4A TSEC 1, 10/100/1000 Ethernet RJ-45
GENET 1 on front
J4B TSEC 2, 10/100/1000 Ethernet RJ-45
GENET2 on front
J11, J12, J13, J14
J21, J22, J23 PMC1
PMC2 Implementing all recommended and
optional VITA32 signals except
RESETOUT#
J1 Port 0. Serial Port 1 Micro DB-9 console serial port on front
P1 VME five-row P1
P2 VME five-row P2 on SBC and RTM TSEC3 signals assigned to E1-1 thru E1-4
TSEC4 signals assigned to E2-1 thru E2-4
Serial ports 2-5
P4 Processor COP header Planar header for processor COP
emulation
P5 Boundary Scan header Planar header for boundary scan and
PLD/flash programming
