Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 62
3.3.3.4 Serial Port Connector (COM1/J1)
There is one front access asynchronous serial port interface (SP0) that is routed to the micro
DB-9 front-panel connector. You can use the Artesyn part MTCA-CONSOLE-CABLE to convert
to a DB9 male connector. The pin assignments for this connector are as follows:
3.3.3.5 VMEbus P1 Connector
The VME P1 connector is a 160-pin DIN. The P1 connector provides power and VME signals for
24-bit address and 16-bit data. The pin assignments for the P1 connector are as follows:
Table 3-12 COM1 Port Connector Pin Assignments
Pin Signal
1 No Connect
2 RX
3 TX
4 No Connect
5 GND
6 No Connect
7 RTS
8 CTS
9 No Connect
Table 3-13 VMEbus P1 Connector Pin Assignments
Pin ROW Z ROW A ROW B ROW C ROW D Pin
1 Reserved (N/C) D00 BBSY* D08 +5V 1
2 GND D01 BCLR* D09 GND 2
3 Reserved (N/C) D02 ACFAIL* D10 Reserved (N/C) 3
4 GND D03 BG0IN* D11 Reserved (N/C) 4
5 Reserved (N/C) D04 BG0OUT* D12 Reserved (N/C) 5
6 GND D05 BG1IN* D13 Reserved (N/C) 6
7 Reserved (N/C) D06 BG1OUT* D14 Reserved (N/C) 7
