Controls, LEDs, and Connectors
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 63
8 GND D07 BG2IN* D15 Reserved (N/C) 8
9 Reserved (N/C) GND BG2OUT* GND GAP_L 9
10 GND SYSCLK BG3IN* SYSFAIL* GA0_L 10
11 Reserved (N/C) GND BG3OUT* BERR* GA1_L 11
12 GND DS1* BR0* SYSRESET* +3.3V (Not Used) 12
13 Reserved (N/C) DS0* BR1* LWORD* GA2_L 13
14 GND WRITE* BR2* AM5 +3.3V (Not Used) 14
15 Reserved (N/C) GND BR3* A23 GA3_L 15
16 GND DTACK* AM0 A22 +3.3V (Not Used) 16
17 Reserved (N/C) GND AM1 A21 GA4_L 17
18 GND AS* AM2 A20 +3.3V (Not Used) 18
19 Reserved (N/C) GND AM3 A19 Reserved (N/C) 19
20 GND IACK* GND A18 +3.3V (Not Used) 20
21 Reserved (N/C) IACKIN* SERA (N/C) A17 Reserved (N/C) 21
22 GND IACKOUT* SERB (N/C) A16 +3.3V (Not Used) 22
23 Reserved (N/C) AM4 GND A15 Reserved (N/C) 23
24 GND A07 IRQ7* A14 +3.3V (Not Used) 24
25 Reserved (N/C) A06 IRQ6* A13 Reserved (N/C) 25
26 GND A05 IRQ5* A12 +3.3V (Not Used) 26
27 Reserved (N/C) A04 IRQ4* A11 Reserved (N/C) 27
28 GND A03 IRQ3* A10 +3.3V (Not Used) 28
29 Reserved (N/C) A02 IRQ2* A09 Reserved (N/C) 29
30 GND A01 IRQ1* A08 +3.3V (Not Used) 30
31 Reserved (N/C) -12V +5VSTDBY
(N/C) +12V GND 31
32 GND +5V +5V +5V +5V 32
Table 3-13 VMEbus P1 Connector Pin Assignments (continued)
Pin ROW Z ROW A ROW B ROW C ROW D Pin
