2.3.5
Equipment Requirements
The following equipments are recommended to complete an MVME4100ET system:
VMEbus system enclosure
System console terminal
Operating system (and/or application software)
Transition module and connecting cables
2.4
Configuring the Board
To produce the desired configuration and ensure proper operation of the MVME4100ET, you
may need to carry out certain hardware modifications before installing the module.
Figure 2-2
Secondary Side Thermally Significant Components
U66 U67
