Page 22: 3 mechanical data 1.4 ordering information, Table 1-3, Mechanical data, Table 1-4, Board variants

Introduction

MVME4100ET Single Board Computer Installation and Use (6806800K76F)

1.3

Mechanical Data

This section provides details on the board’s mechanical data.

1.4

Ordering Information

While ordering board variants or board accessories, use the order numbers given in the
following tables.

1.4.1

Supported Board Models

The MVME4100ET Single Board Computer is available in the configurations shown below.

Table 1-3 Mechanical Data

Characteristic

Value

Dimensions (D x W x H)

6U, 4HP wide, (233.4 mm x 160 mm x 19.8 mm)

Weight

0.453 kg

Table 1-4 Board Variants

Marketing Number

Processor

MVME4100ET-0171

1.3GHZ MPC8548E, 4G NAND FLASH, 2G DDR2-533 SO-CDIMM,
SCANBE at -40C to +71c operating temperature

MVME4100ET-0173

1.3GHZ MPC8548E, 4G NAND FLASH, 2G DDR2-533 SO-CDIMM, IEEE at
-40C to +71c operating temperature
