Hardware Preparation and Installation
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 42
Figure 3-1 on page 46 and Figure 5-1 on page 80 show the locations of the various connectors
on the MVME4100ET and MVME721ET.
The console settings for the MVME4100ET are:
 Eight bits per character
 One stop bit per character
 Parity disabled (no parity)
 Baud rate of 9600 baud
Verify that hardware is installed and the power/peripheral cables connected are appropriate
for your system configuration.
Replace the chassis or system cover, reconnect the chassis to the AC or DC power source, and
turn the equipment power on.
2.8 Factory Installed Linux
A bootable ramdisk based Linux image based on the 2.6.27 kernel is available in NOR flash. To
boot this image, use the following MOTLOAD commands:
MVME4100>
bmw -af8000000 -bf8f00000 -c2000000 execP -l2000400
Product Damage
RJ-45 connectors on modules are either twisted-pair Ethernet (TPE) or E1/T1/J1 network
interfaces. Connecting an E1/T1/J1 line to an Ethernet connector may damage your system.
 Make sure that TPE connectors near your working area are clearly marked as network
connectors.
 Verify that the length of an electric cable connected to a TPE bushing does not exceed
100 m.
 Make sure the TPE bushing of the system is connected only to safety extra low voltage
circuits (SELV circuits).
If in doubt, ask your system administrator.
