Hardware Preparation and Installation
MVME4100ET Single Board Computer Installation and Use (6806800K76F) 38
are not in the same location or if the keying pins are not installed, the PMC sites does not
function. Note that setting the PMC I/O voltage to 5.0 V forces the PMC sites to operate in
33 MHz PCI mode instead of PCI-X mode. The default factory configuration is for 3.3 V PMC I/O
voltage.
Follow these steps to install a PMC onto the MVME4100ET board.
Installation Procedure
Read all notices and follow these steps to install a PMC on the base board.
1. Attach an ESD strap to your wrist.
2. Attach the other end of the ESD strap to the chassis as a ground.
The ESD strap must be secured to your wrist and to ground throughout the
procedure.
3. Remove the PCI filler from the front panel.
4. Slide the edge connector of the PMC module into the front panel opening from
behind and place the PMC module on top of the base board.
The four connectors on the underside of the PMC module should then connect
smoothly with the corresponding connectors on the MVME4100ET.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits or
shorten their life.
Before touching the board or electronic components, make sure that you are working in an
ESD-safe environment.
Product Damage
Inserting or removing modules with power applied may result in damage to module
components.
Before installing or removing additional devices or modules, read the documentation that
is provided with the product.
