Enabling the R2 Protocol
November 2009 348
Protocol Parameter Mechanics
The set of protocol parameters is specified according to a simple
procedure. Individual signal meanings are set to the appropriate MF
tone code. R2 MF tone codes for both forward and backward
channels are defined according to the enumeration in Table 20 . If a
signal is not defined for a particular variant, its value is set to zero.
Table 20. IISDN_R2MF_SIGNAL_CODES Enumeration
Name Forward (Backward) Channel Value
IISDN_R2F_INVALID / IISDN_R2B_INVALID 0
IISDN_R2F_01 / IISDN_R2B_01 1
IISDN_R2F_02 / IISDN_ R2B_02 2
IISDN_R2F_03 / IISDN_R2B_03 3
IISDN_R2F_04 / IISDN_R2B_04 4
IISDN_R2F_05 / IISDN_R2B_05 5
IISDN_R2F_06 / IISDN_R2B_06 6
IISDN_R2F_07 / IISDN_R2B_07 7
IISDN_R2F_08 / IISDN_R2B_08 8
IISDN_R2F_09 / IISDN_R2B_09 9
IISDN_R2F_10 / IISDN_R2B_10 10
IISDN_R2F_11 / IISDN_R2B_11 11
IISDN_R2F_12 / IISDN_R2B_12 12
IISDN_R2F_13 / IISDN_R2B_13 13
IISDN_R2F_14 / IISDN_R2B_14 14
IISDN_R2F_15 / IISDN_R2B_15 15
