BSMI Debugging
November 2009 102
The trace information is embedded within the Bfv API debug output,
see Figure 5 for a sample output. See Table 2 for report heading
information:
Figure 5. Level 2 Trace Example
Ch# Time Direct SAPI TEI C/R Type N(s) N(r) P/F Size
--- ----- -------- ---- ---- --- -------- ---- ---- --- ------
03 23B4 Xmit 3F 7F 0 teiReqst 0 0008
FCFF030F23B501FF
03 23BB Rcvd 3F 7F 1 teiAssgn 0 0008
FEFF030F23B502C1
03 23BB Xmit 00 60 0 SABME 1 0003
03 23C1 Rcvd 00 60 0 UA 1 0003
03 278D Xmit 00 60 0 Setup 00 00 0 0018
00C1000008010105040288901801812C0735353532303030
03 27C2 Rcvd 00 60 1 Prcdng 00 01 0 000B
02C1000208018102180189
03 27C2 Xmit 00 60 1 RR 01 0 0004
03 27DD Rcvd 00 60 1 Alrtng 01 01 0 0008
02C1020208018101
03 27DD Xmit 00 60 1 RR 02 0 0004
03 27FB Rcvd 00 60 1 Connct 02 01 0 0008
02C1040208018107
03 27FB Xmit 00 60 0 ConAck 01 03 0 0008
00C102060801010F
03 280C Rcvd 00 60 0 RR 02 0 0004
03 2E43 Xmit 00 60 0 Discct 02 03 0 000C
00C104060801014508028090
03 2E5E Rcvd 00 60 1 Rlease 03 03 0 0008
02C106060801814D
03 2E5E Xmit 00 60 0 RelCom 03 04 0 0008
00C106080801015A
03 2E71 Rcvd 00 60 0 RR 04 0 0004
00 09F3 Rcvd 00 00 1 Prcdng 00 01 0 000E
0201000208028001021803A98381
