Chapter 11 Specifications|ASDA-B Series
Revision January 2009
11-7
11.3 Dimensions of Servo Drive
Order P/N: ASD-B0121-A, ASD-B0221-A, ASD-B0421-A (100W to 400W)
WEIGHT
1.2 (2.64)
NOTE
1) Dimensions are in millimeters (inches).
2) Weights are in kilograms (kg) and (pounds (lbs))
3) In this manual, actual measured values are in metric units. Dimensions in (imperial
units) are for reference only. Please use metric for precise measurements.
