Chapter 7 Servo Parameters|ASDA-B Series
7-30 Revision January, 2009
P1 - 15▲
GR4
Electronic Gear Ratio (2nd Numerator) (N2) Communication Addr.: 010FH
Default: 1 Related Section:
Applicable Control Mode: P Section 6.2.4, P1-44, P1-45
Unit: pulse DI GNUM0(11) in Table 7.A
Range: 1 ~ 32767
Settings:
The electronic gear numerator value can be set via external DI signal (refer to Table 7.A).
DI Name DI Status Selected Electronic Gear
Not select (Note 1) P1-44, P1-45
0 P1-44, P1-45 GNUM0
1 P1-44, P1-45
NOTE
1) DI signal can be selected by parameter P2-10 to P2-15 and Table 7.A. If uses only need to
use one group of electronic gear, it allows users not to select GNUM0.
P1 - 16
Reserved
Communication Addr.: 0110H
P1 - 17
Reserved
Communication Addr.: 0111H
P1 - 18
Reserved
Communication Addr.: 0112H
P1 - 19
Reserved
Communication Addr.: 0113H
P1 - 20
Reserved
Communication Addr.: 0114H
P1 - 21
Reserved
Communication Addr.: 0115H
P1 - 22
Reserved
Communication Addr.: 0116H
P1 - 23
Reserved
Communication Addr.: 0117H
P1 - 24
Reserved
Communication Addr.: 0118H
P1 - 25
Reserved
Communication Addr.: 0119H
