Setting Up Your OTDR
38 OTDR
Defining Cables
To create a custom color code:
1. From the main window, press Setup.
2. From the Setup dialog box, select the Cable tab.
3. Press the button next to the Color ID box.
4. From the Color Setup dialog box, press New Code.
5. In the Color Name field, enter a color name.
6. Press OK.
You return to the Color Setup dialog box.
The added color code is displayed in the Color Code in Use list. The color
table is empty. You must add color names to the new color code. For more
information on color creation, see the corresponding procedure on
page 43.
