Analyzing Traces and Events
OTDR 145
Selecting the Pulse Width Unit
Selecting the Pulse Width Unit
You can select the unit that is used in the Trace Info window to express the
pulse value. The pulse value can be expressed in units of time or distance
(see Selecting the Distance Units on page 116).
To select the pulse width unit:
1. From the main window, press Setup.
2. From the Setup dialog box, select the General tab.
3. Press the arrow next to the Pulse Width box arrow and select the
desired unit.
4. Press Apply to confirm the changes, then OK to return to the main
window.
Once you exit the Setup dialog box, your selection is displayed in the Trace
Info pane, under Pulse.
Pulse width
unit
