SCPI Command Reference
414 OTDR
Product-Specific Commands—Description
:MMEMory[1..n]:LOAD:TRACe
Description This command is used to load traces from a file.
*RST does not affect this command.
Syntax :MMEMory[1..n]:LOAD:TRACe
e>
Parameter(s) FileName:
The program data syntax for is
defined as a
element.
The parameter can either be only
the filename or the filename and its path.
If no path is specified, the default path is used.
The default path name depends on the location
of the installation directory.
Example(s) MMEM:LOAD:TRAC "Trace1.trc"
Notes No effect on MMEM:DATA:TYPE?
See Also MMEMory[1..n]:DATA:TYPE?
CONFigure[1..n]:ACQuisition:MODE
NITiate[1..n][:IMMediate]
MMEMory[1..n]:STORe:TRACe
