22
OTDR
Starting the OTDR Application
Split Bar
A split bar divides the data display and Control Center. You can drag it up or
down to obtain a larger view of the graph or table display.
Status Bar
The status bar, located at the bottom of the main window, identifies the
operational status of the Optical Time Domain Reflectometer.
For more information about automating or remotely controlling the Optical
Time Domain Reflectometer, refer to your platform user guide.
Current date and time
Local: Module controlled locally only.
Remote: Module controlled remotely, but local
commands can also be used (some products only).
Lockout: Module controlled remotely only.
Battery indicator
Control mode
