Customizing the Application
OTDR 119
Customizing the Acquisition Distance Range Values
To customize the distance range values:
1. From the main window, select Setup, then the Acquisition tab.
2. Press the Customize Settings button.
3. If your OTDR supports singlemode, multimode or filtered wavelengths,
specify the desired fiber type.
4. From the Distance list, select the value you want to modify (the value
will become highlighted), then press the Edit button.
Note: You can revert to factory values by pressing the Default button.
5. In the displayed dialog box, enter the new value and confirm with OK.
Press OK once again to close the Customize Settings dialog box.
You return to the Acquisition tab.
4
3
