Analyzing Bidirectional Traces
OTDR 229
Starting and Exiting the Bidirectional Analysis Utility
The main window contains buttons allowing you to access the following
panes:
³
Results for the A->B trace, presented in a table
³
Results for the B->A trace, presented in a table
³
Results for the bidirectional trace, presented in a table
³
Options to modify span-start and span-end values
³
Information about the A->B trace and settings used
³
Information about the B ->A trace and settings used
³
Information about the bidirectional trace and settings used
To close the application from the main window:
³
Press (in the top right corner of the main window).
³
Press the Exit button located at the bottom of the button bar.
