71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 86 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
Function/Routine
Name
Description Input Output File Name
IICStart() IIC bus's start condition none none iiceep.c
IICStop() IIC bus's stop condition none none iiceep.c
init_meter()
Initializes meter to default
values
none none defaults.c
IRQ_DEFINES
Defines variables used by
macros to enable and
disable interrupts.
n/a n/a irq.h
irq_disable() Disables interrupts. void void irq.c
IRQ_DISABLE()
The fastest way to disable
interrupts. Requires
IRQ_DEFINES to be earlier
in the code, or that the
needed symbols be defined.
n/a n/a irq.h
irq_enable() Enables interrupts void void irq.c
IRQ_ENABLE()
The fastest way to enable
interrupts. Requires
IRQ_DEFINES to be earlier
in the code, or that the
needed symbols be defined.
n/a n/a irq.h
irq_init() Initializes interrupt control. void void irq.c
labs() returns the absolute value int32_t x S332 math.c
latan2() returns the arcTangent int32_t sy, int32_t sx U32 math.c
LCD_CE_Off() displays "CE OFF" on LCD none none lcd.c
LCD_Command()
turns LCD on or off, clears
display
uint8_t LcdCmd none lcd.c
LCD_Config() configures LCD parameters
uint8_t num, enum
eLCD_mode bias, enum
LCD_CLK clock
none lcd.c
LCD_Data_Read()
reads from selected icon of
LCD
uint8_t Icon uint16_t lcd.c
LCD_Data_Write()
writes to selected icon of
LCD uint8_t icon, uint16_t
Mask
none lcd.c
LCD_Hello() displays "HELLO" on LCD none none lcd.c
LCD_Init()
clears LCD, enables LCD
segment drivers
none none lcd.c
LCD_Mode Display a mode number. uint8_t mode none lcd.c
