71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 110 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
Instructions Ordered by Function
Mnemonic Description Code Bytes Cycles
ADD A,Rn Add register to accumulator 28-2F 1 1
ADD A,direct Add direct byte to accumulator 25 2 2
ADD A,@Ri Add indirect RAM to accumulator 26-27 1 2
ADD A,#data Add immediate data to accumulator 24 2 2
ADDC A,Rn Add register to accumulator with carry flag 38-3F 1 1
ADDC A,direct Add direct byte to A with carry flag 35 2 2
ADDC A,@Ri Add indirect RAM to A with carry flag 36-37 1 2
ADDC A,#data Add immediate data to A with carry flag 34 2 2
SUBB A,Rn Subtract register from A with borrow 98-9F 1 1
SUBB A,direct Subtract direct byte from A with borrow 95 2 2
SUBB A,@Ri Subtract indirect RAM from A with borrow 96-97 1 2
SUBB A,#data Subtract immediate data from A with borrow 94 2 2
INC A Increment accumulator 04 1 1
INC Rn Increment register 08-0F 1 2
INC direct Increment direct byte 05 2 3
INC @Ri Increment indirect RAM 06-07 1 3
INC DPTR Increment data pointer A3 1 1
DEC A Decrement accumulator 14 1 1
DEC Rn Decrement register 18-1F 1 2
DEC direct Decrement direct byte 15 2 3
DEC @Ri Decrement indirect RAM 16-17 1 3
MUL AB Multiply A and B A4 1 5
DIV Divide A by B 84 1 5
DA A Decimal adjust accumulator D4 1 1
Table 6-9: Arithmetic Operations
