3) If 0 <= cs <= Scal: For two accumulation intervals, prorated measurements of current and voltage are
added to the variables. Using two accumulation intervals covers both chop polarities of temperature
measurements.
4) If cs = 0: This signals the end of the calibration. Cumulative current and voltage measurements are then
used to calculate and set the calibration coefficients for voltage and currents in CE DRAM.
See the source file calphased.c for details.
CE Default Calibration
ce_def_calibration()
END
set_tc1_tc2 ()
Copy
CE_DATA
image to RAM
Figure 5-15: ce_default Calibration
