71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 84 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
Function/Routine
Name
Description Input Output File Name
LRC_Calc_NVR()
calculates longitudinal parity
on NVRAM uint8_tx *ptr, uint16_t
len, U01 set
bool library.c
ctoh()
converts ascii hex character
to hexadecimal digit
uint8_t c uint8_t load.c
date_lcd () Displays the current date. void void rtc.c
Delta_Time ()
Figure the elapsed time
between two times. struct RTC_t start, struct
RTC_t end
int32_t seconds rtc.c
Determine_Frequenc
y()
Sets the frequency. Uses
sag status and voltage
thresholds to return 0 if the
voltages are off.
void void freq.c
Determine_Peaks()
Sets status bits if voltages,
currents or temperature are
outside limits. Sag tests are
in xfer_busy_int()
void void peak_alerts.c
done() exits control uint8_td *c *c cli.c
EEProm_Config()
connects/disconnects
DIO4/5 for I2C interface to
serial EEPROM
bool access, uint16_t
page_size, uint8_t tWr
none
eeprom.c,
eepromp3.c
es0_isr () serial port 0 service routine none none ser0.c
es1_isr() serial port 1 service routine none none se1.c
flag0_in()
Input interrupt for FLAG
AMR module on SER0
none none flag0.c3
flag0_initialize()
Initialize the FLAG AMR
module on SER0
none none flag0.c3
flag0_out()
Output interrupt for FLAG
AMR module on SER0
none none flag0.c3
flag0_run()
Run main loop logic for
FLAG AMR module on
SER0
none none flag0.c3
flag1_in()
Input interrupt for FLAG
AMR module on SER1
none none flag1.c3
flag1_initialize()
Initialize the FLAG AMR
module on SER1
none none flag1.c3
