71M652X Software User’s Guide
Revision 1.7 TERIDIAN Proprietary 132 of 138
© Copyright 2005-2007 TERIDIAN Semiconductor Corporation
4 Comparator rising automatic
5 EEPROM busy falling automatic
6 XFER_BUSY OR RTC_1SEC falling manual
Table 6-54: External MPU Interrupts
Enable Bit Description Flag Bit Description
EX0 Enable external interrupt 0 IE0 External interrupt 0 flag
EX1 Enable external interrupt 1 IE1 External interrupt 1 flag
EX2 Enable external interrupt 2 IEX2 External interrupt 2 flag
EX3 Enable external interrupt 3 IEX3 External interrupt 3 flag
EX4 Enable external interrupt 4 IEX4 External interrupt 4 flag
EX5 Enable external interrupt 5 IEX5 External interrupt 5 flag
EX6 Enable external interrupt 6 IEX6 External interrupt 6 flag
EX_XFER Enable XFER_BUSY interrupt IE_XFER XFER_BUSY interrupt flag
EX_RTC Enable RTC_1SEC interrupt IE_RTC RTC_1SEC interrupt flag
Table 6-55: Control Bits for External Interrupts
SFR (special function register) enable bits must be set to permit any of these interrupts to occur. Likewise, each
interrupt has its own flag bit which is set by the interrupt hardware and is reset automatically by the MPU interrupt
handler (0 through 5). XFER_BUSY and RTC_1SEC, which are OR-ed together, have their own enable and flag bits in
addition to the interrupt 6 enable and flag bits (see Table 6-52), and these interrupts must be cleared by the MPU
software.
Interrupt Priority 0 Register (IP0)
MSB LSB
OWDS WDTS IP0.5 IP0.4 IP0.3 IP0.2 IP0.1 IP0.0
Table 6-56: The IP0 Register
Note: OWDS, WDTS are not used for interrupt controls
Interrupt Priority 1 Register (IP1)
MSB LSB
- - IP1.5 IP1.4 IP1.3 IP1.2 IP1.1 IP1.0
Table 6-57: The IP1 Register
IP1.x IP0.x Priority Level
0 0 Level0 (lowest)
0 1 Level1
1 0 Level2
1 1 Level3 (highest)
Table 6-58: Priority Levels
External interrupt 0 Polling sequence
UART 1 interrupt
Timer 0 interrupt
External interrupt 2
